Eagle burgmann type 155 pump mechanical seal

  • Replacement of original eagle burgmann 155 seal
Facebook
Twitter
LinkedIn

Description:

Single spring design, Unbalanced seal, Free rotation direction, Used in water pump.

Operating Limits:

  • Temperature:-10—160℃
  • Speed: 10m/s
  • Pressure: 5bar
  • Standard size: 10mm–100mm

Materials:

  • Seal ring: Car,Sic,Ssic,TC
  • Secondary seal: NBR,EPDM,Viton etc.
  • Spring and metal parts:304,316
Eagle burgmann type 155 pump mechanical seal front view
Eagle burgmann type 155 pump mechanical seal right view
Eagle burgmann type 155 pump mechanical seal left view

Some others you may like

155 Seal Matching Beyond Shaft Diameter

For a 155 replacement, the shaft diameter is only the starting point. Include the stationary seat dimensions and installed working length in your inquiry, alongside a photo of the removed seal. These details help distinguish assemblies that share a nominal size but occupy different spaces inside the pump.

Material Options with a Clear Purpose

This model offers carbon, silicon carbide and tungsten carbide face options, with NBR, EPDM or FKM secondary seals. Tell us what the pump actually handles, including additives and suspended particles, so the quotation can identify a material combination for review rather than leave the seal specification open.

Separate Water Duty from Cleaning Duty

A water pump may encounter a different liquid during flushing or cleaning. Add that liquid and its temperature to the inquiry, together with normal pressure and shaft speed. The published limits for this 155 seal are a selection reference; the chosen faces and elastomer still need to suit the full operating cycle.

A Replacement Specification You Can Reuse

Keep the confirmed seat type, working length and material codes with your pump maintenance record. When ordering another 155 seal, refer to that specification and note any changes in service. This gives the next inquiry a defined starting point instead of relying on the model name or an old photograph alone.
