John crane SAF-055-QREG mechanical seal in paper making industry

  • Replacement of John crane SAF-055-QREG safematic mechanical seal , cartridge type, used in paper making industry
Facebook
Twitter
LinkedIn

Description:

Equivalent to John crane SAF-055-QREG mechanical seal in paper making industry, Double cartridge seal, Strong corrosion resistance

Operating Limits:

  • Temperature:-40—200℃
  • Speed: 15m/s
  • Pressure: 20bar
  • Shaft diameter: 55 mm

Materials:

  • Seal ring: Car,Sic,Ssic,TC
  • Secondary seal: NBR,EPDM,Viton etc.
  • Spring and metal parts:304,316,HAST.C
John crane SAF-055-QREG mechanical seal in paper making industry front view
SAF-055-QREG mechanical seal
John crane SAF-055-QREG mechanical seal in paper making industry right view

Some others you may like

Our Advantages

A 55 mm Shaft Is Only the Starting Point

For a SAF-055-QREG replacement, send the old cartridge drawing or measured sample together with the pump model. Compare the sleeve fit, gland register, bolt spacing and installed length before ordering. This gives your maintenance team a defined fit check beyond the nominal 55 mm shaft size.

Describe the Stock, Then Choose the Materials

A paper-machine pump may handle fibre stock, white water or a changing mix of both. Include stock consistency, temperature, pH and cleaning chemicals in your enquiry. Use those details to narrow the face and elastomer options listed for this seal, rather than treating every material combination as equally suitable.

Keep the Seal-Water Connections in the Review

The double cartridge and its liquid supply need to be reviewed together. Share the existing piping arrangement, connection sizes and available supply pressure with the seal dimensions. Confirm the required liquid quality, pressure and flow for the selected assembly before commissioning; do not infer these settings from shaft size alone.

Give the Next Shutdown a Clear Spare Specification

Record the approved SAF-055 assembly drawing, face pairing, elastomer grade and port arrangement against the pump asset number. Keep photographs of the removed seal with that record. A repeat enquiry can then identify the same configuration even when several similar pulp-pump cartridges are stored in the workshop.
